DHI-VTO4202F-P-S2

Modular de Estación de Puerta de Apartamento de 2MP para DHI-VTO4202F

Modular de Estación de Puerta de Apartamento de 2MP para DHI-VTO4202F

  • Panel frontal de aluminio anodizado
  • Cámara ojo de pez CMOS de baja iluminación de 2MP HD colorida de 160°
  • Función de videoportero
  • Función de control de acceso que admite dos cerraduras
  • Aplicación de teléfono móvil, hable con el visitante o desbloquee la puerta de forma remota en su teléfono
  • Compatibilidad Interfaz de 2 hilos e interfaz RJ45
  • IK07 & IP65
  • Soporte H.265
  • Superficie de apoyo y montaje empotrado
  • Los módulos hacen que el dispositivo tenga una gran capacidad de expansión
Ver datasheet

System

Main Processor
Embedded processor
Operating System
Embedded Linux Operation System
Button Type
Mechanical
Interoperability
ONVIF; CGI
Network Protocol
SIP; P2P; IPv4; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP

Basic

Camera
1/2.5" 2MP CMOS Low Illumination HD Colorful Fisheye Camera
Field of View
Horizontal: 168.6°; vertical: 87.1; diagonal:176.7°
Focal Length
1.9 mm
WDR
120 dB
Noise Reduction
3D DNR
Video Compression
H.265
Video Resolution

50Hz: Main Stream ([email protected] fps), sub stream ([email protected] fps) 60Hz:

Main Stream ([email protected] fps), sub stream ([email protected] fps)

Video Frame Rate
25 fps
Video Bit Rate
256 Kbps to 4 Mbps
Light Compensation
Auto IR
Day/Night
Auto (ICR)
Audio Compression
G.711a; G.711u; PCM
Audio Input
1 channel
Audio Output
Built-in speaker
Audio Mode
2-way voice communication
Audio Enhancement
Echo suppression/digital noise reduction
Audio Bit Rate
16 KHz, 16 Bit
Status Indicator Light
3

Port

RS-485 Port
1
Alarm Output
1
Power Output
1-ch 12 VDC 100mA
Exit Button
1
Door Status Detection
1
Lock Control
1
Network Port
One RJ45 10M/100M network port

General

Appearance color
Silver
Power Supply

Dahua 2-wire switch (max. power supply distance 50 m) DC 48V 1A

Standard PoEvvvvvvvvvv

Power Adapter
Optional
Installation
Flush/surface mount
Certifications
CE; FCC; UL
Accessory
Flush/surface mount
Product Dimensions
100 mm × 100 mm × 36 mm (3.94" × 3.94" × 1.41")
Protection
IK07; IP65
Operating Temperature
–30°C to +60°C (–22°F to 140°F)
Operating Humidity
10%–90% (RH, non-condensing)
Operating Altitude
0 m–3000 m
Power Consumption
= 12W
Net Weight
0.35 kg (0.77 lb)
Gross Weight
0.4 kg (0.88 lb)
